HARDWARE-FUNKTIONEN
Schnittstelle: USB 3.0
Abmessungen (B*T*H): 1.59 × 0.78 × 0.41in. (40.5 × 19.72 × 10.29mm)
Antennentyp: Omni Directional
WLAN-FUNKTIONEN
WLAN-Standards: IEEE 802.11ac, IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequenz: 5GHz; 2.4GHz
Signalrate:
5GHz
11ac: Up to 867Mbps(dynamic)
11n: Up to 300Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
2.4GHz
11n: Up to 400Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Empfängerempfindlichkeit
5GHz：
11a 6Mbps: -91dBm
11a 54Mbps: -76dBm
11n HT20：-71dBm
11n HT40：-70dBm
11ac HT20: -68dBm
11ac HT40: -64dBm
11ac HT80: -62dBm
2.4GHz:
11b 11Mbps: -86dBm
11g 54Mbps: -73dBm
11n HT20: -71dBm
11n HT40: -70dBm
Sendeleistung <23dBm (EIRP)
WLAN-Modi: Ad-Hoc / Infrastructure Mode
WLAN-Sicherheit Support: 64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Modulationsverfahren: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM
SONSTIGES
Zertifizierung: CE, FCC, RoHS
Systemanforderungen: Windows 10/8.1/8/7/XP, Mac OS X
Umgebung
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
